ASUS AMD B550 TUF GAMING B550-PLUS (WI-FI) ATX MB, PCIe 4.0, Dual M.2, 10 DrMOS Power Stages, 2.5Gb LAN, HDMI, DP, Wi-Fi 6 (LS)

ASUS TUF GAMING B550-PLUS (WI-FI) AMD B550 (Ryzen AM4) ATX gaming motherboard with PCIe 4.0, dual M.2, 10 DrMOS power stages, Intel Wi-Fi 6, 2.5 Gb Ethernet, HDMI, DisplayPort, SATA 6 Gbps, USB 3.2 Gen 2 Type-A and Type-C, Thunderbolt??? 3 header, and Aura Sync RGB lighting support
AMD AM4 socket: Ready for 3rd Gen AMD Ryzen??? processors
Enhanced power solution: 8+2 DrMOS power stages, ProCool sockets, military-grade TUF components, and Digi+ VRM for maximum durability
Comprehensive cooling: VRM heatsink, PCH fanless heatsink, Dual M.2 heatsink, hybrid fan headers and Fan Xpert 4 utility
Next-gen connectivity: PCIe 4.0 M.2, USB 3.2 Gen 2 Type-A and Type-C, Thunderbolt??? 3 header support
Made for online gaming: Intel Wi-Fi 6, 2.5 Gb Ethernet, TUF LANGuard, and Turbo LAN technology
Realtek S1200A codec: Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in
AI noise-canceling microphone: provides crystal-clear in-game voice communication

Chipset AMD B550
Memory 3rd Gen AMD Ryzen??? Processors
3rd Gen AMD Ryzen?????with Radeon?????Graphics Processors
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
Graphic 1 x DisplayPort 1.2
1 x HDMI 2.1(4K@60HZ)
Multi-GPU Support Supports AMD 2-Way CrossFireX Technology
Expansion Slots 3rd Gen AMD Ryzen??? Processors
1 x PCIe 4.0 x16 (x16 mode)
3rd Gen AMD Ryzen?????with Radeon?????Graphics Processors
1 x PCIe 3.0 x16 (x16 mode)
AMD B550 Chipset
1 x PCIe 3.0 x16 (x4 mode)
3 x PCIe 3.0 x1
Storage Total supports 2 x M.2 slot(s) and 6 x SATA 6Gb/s ports
6 x SATA 6Gb/s port(s),
Support Raid 0, 1, 5, 10
LAN Realtek RTL8125B 2.5Gb Ethernet
TUF LANGuard
ATX Form Factor 30.5 cm x 24.4 cm
