ASUS -PEI-10G/82599-2S

Intel?? LGA2066 ATX motherboard with complete IT infrastructure management supporting Intel?? Xeon?? processor and ECC memory

Powered by Intel?? Xeon?? W processor with ECC memory
ASUS Control Center – A software utility that provides convenient, secure and cost-saving centralized IT management for small and medium businesses
Server-grade design with built-in dual Intel Gigabit LAN
Next-gen transfer speeds – Up to 32Gbps dual M.2 and U.2, plus up to 10Gbps USB 3.1 Type-A and Type-C connections
Ultimate graphics power with 2/3-Way NVIDIA?? SLI??? and AMD?? Crossfire X???
Ultra-efficient VRM heatsink – Metal fin array connected to large surface area via a heatpipe tames C422 thermals to enable unthrottled performance

CPU
Intel?? Socket 2066 Processors
Supports Intel?? 14 nm CPU
Supports Intel?? Turbo Boost Max Technology 2.0
* The Intel?? Turbo Boost Technology 2.0 support depends on the CPU types.

Chipset
Build in Intel?? C422

Memory
8 x DIMM, Max. 512GB, DDR4 2666/2400/2133 MHz RDIMM, LR-DIMM Memory *1
Quad Channel Memory Architecture

Graphic
ASPEED AST2500 64MB
VGA output support : Header port

Multi-GPU Support
Supports NVIDIA?? 3-Way SLI??? Technology
Supports AMD 3-Way CrossFireX??? Technology

Expansion Slots
48-Lane CPU-
2 x PCIe 3.0 x16 (x16 mode)
2 x PCIe 3.0 x16 (Single at x16, dual at x8/x8)
1 x PCIe 3.0 x4 (x4 mode)

Storage
1 x M.2 x4 Socket 3*2, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
1 x M.2 x4 Socket 3*3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode)
1 x U.2 connector*2
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel?? Rapid Storage Technology Enterprise supports
Intel?? Virtual RAID (VROC) support for CPU RAID

LAN
Intel?? I210-AT, 2 x Gigabit LAN Controller(s)
