Intel® Xeon® E-2274G Processor, 8Mb Cache, 4.00 GHz, 4 Cores, 8 Threads, LGA1151, 83w, 1 Year Warranty

Performance
# of Cores
4

# of Threads
8

Processor Base Frequency
4.00 GHz

Max Turbo Frequency
4.90 GHz

Cache
8 MB

TDP
83 W

Supplemental Information
Embedded Options Available
No

Description
Support for up to 128GB system memory may require a BIOS update. Please contact your hardware provider regarding availability for your system.

Datasheet
View now

Product Brief
View now

Memory Specifications
Max Memory Size (dependent on memory type)
128 GB

Memory Types
DDR4-2666

Max # of Memory Channels
2

ECC Memory Supported ???
Yes

Processor Graphics
Processor Graphics ???
Intel?? UHD Graphics P630

Graphics Base Frequency
350 MHz

Graphics Max Dynamic Frequency
1.20 GHz

Graphics Video Max Memory
128 GB

4K Support
Yes, at 60Hz

Max Resolution (HDMI 1.4)???
4096×2160@24Hz

Max Resolution (DP)???
4096×2304@60Hz

Max Resolution (eDP – Integrated Flat Panel)???
4096×2304@60Hz

Max Resolution (VGA)???
N/A

DirectX* Support
12

OpenGL* Support
4.5

Intel?? Quick Sync Video
Yes

Intel?? InTru??? 3D Technology
Yes

Intel?? Clear Video HD Technology
Yes

Intel?? Clear Video Technology
Yes

# of Displays Supported ???
3

Device ID
0x3E96

Expansion Options
Scalability
1S Only

PCI Express Revision
3.0

PCI Express Configurations ???
1×16,2×8,1×8+2×4

Max # of PCI Express Lanes
16

Package Specifications
Sockets Supported
FCLGA1151

Max CPU Configuration
1

TCASE
69.3??C

TJUNCTION
100

Package Size
37.5 mm x 37.5 mm

Advanced Technologies
Intel?? Optane??? Memory Supported ???
Yes

Intel?? Turbo Boost Technology ???
2.0

Intel?? vPro??? Platform Eligibility ???
Yes

Intel?? Hyper-Threading Technology ???
Yes

Intel?? Virtualization Technology (VT-x) ???
Yes

Intel?? Virtualization Technology for Directed I/O (VT-d) ???
Yes

Intel?? VT-x with Extended Page Tables (EPT) ???
Yes

Intel?? TSX-NI
Yes

Intel?? 64 ???
Yes

Instruction Set
64-bit
