Intel NUC i3-10110U 4.1GHz 2xDDR4 SODIMM 2.5′ HDD M.2 PCIe SSD HDMI USB-C DP1.2 3xDisplays GbE LAN WiFi BT no AC cord ~BXNUC10I3FNKN2

Intel NUC mini PC i3-10110U 4.1GHz 2xDDR4 SODIMM 2.5′ HDD M.2 PCIe SSD HDMI USB-C (DP1.2) 3xDisplays GbE LAN WiFi BT 6xUSB DS POS

Essentials
Product Collection Intel?? NUC Kit with 10th Generation Intel?? Core??? Processors
Code Name Products formerly Frost Canyon
Status Launched
Launch Date Q4’19
Supported Operating Systems Windows 10, 64-bit*
Board Number NUC10i3FNB
Board Form Factor UCFF (4′ x 4′)
Socket Soldered-down BGA
Internal Drive Form Factor M.2 and 2.5′ Drive
# of Internal Drives Supported 2
Lithography 14 nm
TDP 25 W
DC Input Voltage Supported 19 VDC
Processor Included Intel?? Core??? i3-10110U Processor (4M Cache, up to 4.10 GHz)
Intel vPro?? Platform Eligibility ??? No
# of Cores 2
# of Threads 4
Processor Base Frequency 2.10 GHz
Max Turbo Frequency 4.10 GHz
Warranty Period 3 yrs
Supplemental Information
Embedded Options Available No
Datasheet View now
Description Other features: Includes far-field quad array microphones
Memory & Storage
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-2666 1.2V SO-DIMM
Max # of Memory Channels 2
Max Memory Bandwidth 42.6 GB/s
Max # of DIMMs 2
ECC Memory Supported ??? No
Processor Graphics
Processor Graphics ??? Intel?? UHD Graphics for 10th Gen Intel?? Processors
Integrated Graphics ??? Yes
Graphics Output HDMI 2.0b; USB-C (DP1.2)
# of Displays Supported ??? 3
Expansion Options
PCI Express Revision Gen3
PCI Express Configurations ??? M.2 slot with PCIe X4 lanes
Removable Memory Card Slot SDXC with UHS-II support
M.2 Card Slot (storage) 22×42/80
