Ubiquiti AmpliFi High Density Mesh Point – 802.11ac Wi-Fi Mesh Extender – For use with AmpliFi Range of Mesh Access Points

Ubiquiti AmpliFi MeshPoint HD – WiFi Extender

The AmpliFi MeshPoint HD features an adjustable super antenna. It can be used to expand the coverage of an AmpliFi Mesh System or turn an existing router or Wi-Fi cablebox into a powerful mesh network.

The AmpliFi MeshPoint features an adjustable Super Antenna and fits discreetly in any household, wherever dead spots need coverage. Add MeshPoints as needed to an AmpliFi network or turn an ordinary router into a powerful mesh network. Signal strength LEDs are integrated into the design to ensure the system is positioned for optimal performance.

MeshPoint Specifications

Dimensions
243.83 x 54 x 57.75

Weight
224 g

Max. TX Power
26 dBm

Radios
2

MIMO Chains
6

Speed
1750 Mbps

ESD/EMP Protection ??
24kV Air/Contact

Buttons
Reset

Antennas
1x Dual-Band Antenna, Tri-Polarity

Wi-Fi Standards
802.11ac

Power Save
Supported

Wireless Security
WPA2-PSK AES/TKIP

Operating Temperature
14 to 131?? F (-10 to 55?? C)

Operating Humidity
5 to 95% Noncondensing

Certifications
FCC / CE / IC

Supported Data Rates

802.11ac
13 Mbps to 1300 Mbps (MCS0 – MCS9, VHT 20/40/80)

802.11n
6.5 Mbps to 450 Mbps (MCS0 – MCS23, HT 20/40)

802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b
1, 2, 5.5, 11 Mbps

802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
